Product Details

Miracle M600 Linux

Linux Smart POS Terminal – Beyond Smart POS

  • LINUX
  • 4" TFT QVGA 480×800 touch
  • 4G + 2G(A5/3 suport) + Wi-Fi 2.4 GHz + BT 4.2
  • Li-polymer 3.7 V 5000 mAh (2*2500Mah 18650)
  • 1 Micro + 1 Normal + 1 SAM
  • 146.9 × 79 x 57 mm 285 g
Download Catalog:

Description

The Miracle M600 Linux is a powerful, reliable, and highly versatile smart payment terminal built on a stable Linux operating system. Designed for high-volume merchants and demanding environments, it offers advanced features, robust connectivity, and exceptional user experience.

Key Features:

  • Larger 4" High-Resolution Display – Clear and vibrant screen for easy operation
  • Powerful ARM Cortex-A7 Processor – Fast and efficient performance
  • Glass Keyboard Technology with Backlight – Durable and visible in low-light conditions
  • Multiple Connectivity Options – 4G, Wi-Fi, Bluetooth, and more
  • PCI PTS 7.x & EMV L1/L2 Certified – Top-level payment security
  • High-Speed Thermal Printer – Fast receipt printing
  • Long-Lasting Battery – Up to 5200mAh for extended use
  • NFC Payment Ready – Contactless transactions supported

Why Choose Miracle M600 Linux?

  • Stable Linux Platform – Ideal for custom applications and long-term reliability
  • Advanced Security – Full PCI and EMV compliance with secure key injection
  • User-Friendly Design – Large screen and backlit glass keyboard for comfortable daily use
  • Versatile Connectivity – Ready for any business environment

Whether you run a busy retail store, restaurant, or delivery service, the Miracle M600 Linux delivers consistent performance and peace of mind in every transaction.

Technical Specifications

OS:

LINUX

Processor:

ARM Cortex-A7 1.2 GHz; MH2101- SP: 32 bit Cortex-M0 96 MHz AP & SP & GSM seprate

Memory:

128 MB RAM + 128 MB Flash

Card Readers:

Chip & PIN /NFC/Magnetic Stripe

NFC Reader:

13.56 MHz ISO/IEC 14443 A/B

Camera:

0.3 MP rear

Display:

4" TFT QVGA 480×800 touch

Comms:

4G + 2G(A5/3 suport) + Wi-Fi 2.4 GHz + BT 4.2

Battery:

Li-polymer 3.7 V 5000 mAh (2*2500Mah 18650)

Printer:

30 lines/s, Ø 40 mm roll

SIM/SAM:

1 Micro + 1 Normal + 1 SAM

Keys:

Numeric ×10 + Function x8 + Power x1

Audio:

Buzzer Speaker(Optional-0.8USD)

USB:

Type-C OTG

Adapter:

Input AC 100-240 V Output 5 V/1 A

Size/Weight:

146.9 × 79 x 57 mm 285 g

Temperature:

-10~ 50 °C operation

Certifications:

PCI 7.x/ EMV L1/L2 / EMV Pure Kernel Support

Charger:

5V 3A

Cable:

1m TypeA-TypeC

GPS:

AGPS, GPS, GLONASS, BEIDOU (optional-2USD)
