Miracle M300 (RTOS)

Enterprise Smart Payment Terminal

  • RTOS
  • 2.8" TFT QVGA 320×480 touch
  • 4G + Wi-Fi 2.4 GHz + BT 4.2
  • Li-polymer 3.7 V 2600 mAh
  • 1 Micro + 1 Normal + 1 SAM
  • 146.9 × 79 x 57 mm 285 g
Download Catalog:

Description

The Miracle M300 RTOS is a compact, robust, and highly secure payment terminal designed for enterprise environments. Powered by a real-time operating system (RTOS), it offers exceptional stability, fast boot time, and enhanced security features, making it the ideal choice for high-volume merchants, chain stores, and mission-critical operations.

Key Features:

  • Real-Time Operating System (RTOS) – Ultra-stable and fast performance with minimal downtime
  • PCI PTS 7.x Certified – Highest level of payment security
  • EMV L1 & L2 Certified – Full compliance with international card standards
  • Glass Surface Keyboard with Backlight – Excellent visibility and durability, even in low-light conditions
  • Powerful Performance – Reliable processing for smooth daily operations
  • Long-Lasting Battery – Up to 5200mAh for extended usage
  • Multiple Connectivity Options – 4G, Wi-Fi, Bluetooth
  • NFC Payment Ready – Contactless payments supported
  • Local & Remote Key Injection – Advanced key management security

Why Choose Miracle M300 RTOS?

  • Enterprise-Grade Security – Ideal for environments requiring strict compliance
  • Reliable Performance – Built to handle high transaction volumes without failure
  • User-Friendly Design – Backlit glass keyboard for easy operation in any lighting
  • Global Compliance – Certified for major international markets

Whether you operate a large retail chain, transportation service, or any business that needs a dependable payment solution, the Miracle M300 RTOS delivers consistent performance and peace of mind.

Technical Specifications

OS:

RTOS

Processor:

ARM Cortex-A7 1.2 GHz; MH2101- SP: 32 bit Cortex-M0 96 MHz AP & SP & GSM seprate

Memory:

AP 128 MB RAM + 16 MB Flash

Card Readers:

Chip & PIN / NFC / Magnetic Stripe

NFC Reader:

13.56 MHz ISO/IEC 14443 A/B

Camera:

0.3 MP rear

Display:

2.8" TFT QVGA 320×480 touch

Comms:

4G + Wi-Fi 2.4 GHz + BT 4.2

Battery:

Li-polymer 3.7 V 2600 mAh

Printer:

30 lines/s, Ø 40 mm roll

SIM/SAM:

1 Micro + 1 Normal + 1 SAM

Keys:

Numeric x10 + Function x8 + Power x1

Audio:

Buzzer

USB:

Type-C OTG

Adapter:

Input AC 100-240 V Output 5 V/1 A

Size/Weight:

146.9 × 79 x 57 mm 285 g

Temperature:

-10~ 50 °C operation

Certifications:

PCI 7.x/ EMV L1/L2 / EMV Pure Kernel Support

Charger:

5V 1A

Cable:

1m TypeA-TуpеC

GPS:

-
